Features
- 40 GbE, PoE+ RJ45 ports
- 8 GbE, PoE++ RJ45 ports
- 4 10G SFP+ ports
- 1 USP RPS DC input for power redundancy
- 600W total PoE availability

Specifications
Mechanical
- Dimensions 442.4 x 399.6 x 43.7 mm
- Weight Without Brackets: 6.25 kg
- Weight With Brackets: 6.34 kg

Hardware
- Networking Interface:
* (48) 10/100/1000 RJ45 Ports
* (4) 1/10G SFP+ Ethernet Ports
- Management Interface: Ethernet In-Band
- Total Non-Blocking Throughput: 88 Gbps
- Switching Capacity: 176 Gbps
- Forwarding Rate: 130.944 Mpps
- Power Method
- Universal Input: 100-240VAC/50-60 Hz
- USP RPS DC Input: 52VDC, 11.54A; 11.5VDC, 5.22A
- Power Supply: AC/DC, Internal, 660W
- Supported Voltage Range: 100 to 240VAC
- Max. Power Consumption (Excluding PoE Output): 60W
- LEDs System: Status
- RJ45 Data Ports: PoE; Speed/Link/Activity
- SFP+ Data Ports:Link/Activity
- ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
- Shock and Vibration: ETSI300-019-1.4 Standard
- Operating Temperature: -5 to 40° C (23 to 104° F)
- Operating Humidity: 10 to 90% Noncondensing
- Certifications: CE, FCC, IC

PoE
- Total Available PoE: 600W
- PoE Interfaces
* Ports 1-40: PoE/PoE+ (pins 1, 2+; 3, 6-)
* Ports 41-48: 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-)
- Max. PoE Wattage per Port by PSE
* PoE+: 32W
* PoE++: 64W
- Voltage Range PoE Mode: 44-57V
- Voltage Range PoE+ Mode: 50-57V
