- Industrial-grade Ethernet cable that protects your network from elemental and electrostatic damage.
- UISP Cable Carrier is an industrial category 5e shielded cable with multi-layer protection from the environment.
The reinforced construction allows UISP Cable Carrier to operate in harsh climatic conditions, the outer sheath reliably protects the cable from rain and snow and other adverse weather conditions.

Reliable solutions for perfect data transmission
- The discharge conductor and internal shielding provide maximum protection against failure due to electrostatic discharge. The use of higher category cable ensures that there is no signal loss due to mutual twisting of cables.
These properties of the Ubiquiti UISP Cable Carrier allow it to achieve stable data rates even in the presence of electromagnetic interference.

Features
- Category 5e cable
- Insulated, weatherproof cable jacket
- Internal foil shielding and drain wire for increased ESD damage protection
- Cable length 305 m

Specifications
- Mechanical
- Box dimensions: 330 x 425 x 340 mm (13 x 16.7 x 13.4")
- Box weight: 16 kg (35.3 lb)
- Cable lenght: 305 m (1,000 ft)
- Cable color: Black
- Cable type: CAT5e, shielded
- Ethernet support: Up to 1 Gbps
- Conductor wire gauge: 24 AWG
- Conductor: Solid bare copper
- Conductor diameter: 0.500 ± 0.005 mm
- Insulation type: Solid polyethylene
- Insulation thickness: Avg. 0.295 mm
- Min.: 0.29 mm
- Insulation diameter: 1.16 ± 0.02 mm
- Separation (Polyester wrapping): Thick: 0.025 mm
- Extent: 20 mm
- Anti-crosstalk divider: LDPE: 4.2*0.3 mm
- Cable shield (Aluminum foil). Thick: 0.060 mm
- Extent: 20 mm
- ESD drain wire: 0.4 TC
- Rip cord: Yes
- Secondary cable shield (Braid): 16*8*0.16AA
- Density: 95%
- Jacket material: Polyethylene
- Jacket thickness: Avg. 0.52 mm
- Min.: 0.46 mm
- Jacket outer diameter: 6.8 ± 0.30 mm
- Jacket color: Black
- Storage temperature: -30 to 75° C (-22 to 167° F)
- Installation temperature: -20 to 60° C (-4 to 140° F)
- Ambient operating temperature: -40 to 80° C (-40 to 176° F)
- Standards:
• ANSI/TIA-568-C.2 (2009)
• ISO/IEC 11801 (Edition 2.2)
