Features
- IEEE 802.3af compliant
- Delivers power up to 100 meters
- Optional 12V DC or 5V DC power supply
- Plug-and-Play, requires no configuration

Specifications
- Standards and Protocols:
* IEEE 802.3, 802.3u, 802.3af
* CSMA/CD, TCP/IP
- Basic Function:
* Compatible with IEEE 802.3af compliant PSEs
* Delivers power up to 100 meters
* Optional 12VDC or 5VDC power supply
* Plug-and-Play
- Ports:
* LAN Port - 1× 10/100M Auto-Negotiation RJ45 port (Auto MDI/MDIX)
* PoE Port - 1× 10/100M Auto-Negotiation RJ45 port (Auto MDI/MDIX)
- Network Media:
*10BASE-T: UTP category 3, 4, 5 cable (max. 100m)
* EIA/TIA-568 100 Ohm STP (max. 100m)
* 100BASE-TX: UTP category 5, 5e cable (max. 100m)
* EIA/TIA-568 100 Ohm STP (max. 100m)
- LED Indicator: PWR
- Safety & Emission: FCC, CE
- Dimensions (W×D×H): 81×52×24 mm
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
- Power Output: 12W (12VDC) or 11.5W (5VDC)
