Features
- Cutting-edge 4G network - Share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps
- Plug a SIM card and play - No configurations needed, compatibility of SIM cards in 100+ countries are assured by years of field tests
- Two detachable advanced LTE antennas - Enjoy stable and efficient connections to every device thanks to the two external antennas
- Wi-Fi router mode - Plug an Ethernet cable into the LAN/WAN port for flexible access as a backup option if you cant get a 4G connection

Specifications
HARDWARE FEATURES
- Interface:
* 1× 10/100Mbps LAN Port, 1 10/100Mbps LAN/WAN Port,
* 1× Micro SIM Card Slot
- Button: WPS/Reset Button
- External Power Supply: 9V/0.85A
- Dimensions (W×D×H): 154×114×36 mm
- Antenna: 2× Detachable External 4G LTE Antennas

WIRELESS FEATURES
- Wireless Standards: IEEE 802.11b/g/n
- Frequency: 2.4 GHz
- Signal Rate: 300 Mbps
- Reception Sensitivity:
* 11g 54M: -74 dBm
* 11n HT20: -71 dBm
* 11n HT40: -68 dBm
- Transmit Power: < 20 dBm (2.4 GHz)
- Wireless Functions: Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics
- WAN Failover: Yes
- Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
- Network Type:
* 4G: FDD-LTE: B1/B3/B5/B7/B8/B20 (2100/1800/850/2600/900/800 MHz)
* TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)
* 3G: HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz)

SOFTWARE FEATURES
- Security: IPv4 SPI Firewall, IP and MAC Address Binding
- Operating Modes: 3G/4G Router, Wireless Router
- WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
- Management: Local Management, Remote Management
- DHCP: Server, DHCP Client List, Address Reservation
- Port Forwarding: ALG, Virtual Server, Port Triggering, UPnP, DMZ
- Dynamic DNS: DynDns, NO-IP
- Protocols: IPv4, IPv6
- Guest Network: 2.4 GHz Guest Network
- Administration: Upgrade Firmware, Factory Default, System Log, Diagnostic Tools

OTHERS
- Certification: CE, RoHS
- Package Contents: 300 Mbps Wireless N 4G LTE TL-MR100, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide
- Requirements:
* Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
* Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
* Java-enabled browser
* Micro SIM Card
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
