HARDWARE FEATURES
- Interface: 1× 2.5G Ethernet Port
- Button: Reset
- Power Supply: 802.3at PoE or 12V/2.5A DC
- Power Consumption
• 25.44 W (For PoE);
• 22.57 W (For DC)
- Dimensions ( W x D x H ): 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)
- Antenna Type
• 2.4 GHz: 2× 4.0 dBi
• 5 GHz: 2× 5.0 dBi
• 6 GHz: 2× 5.0 dBi
- Bluetooth: 1 × 4.0 dBi, Bluetooth 5.2
*Firmware update may be required.
- Mounting: Ceiling / Wall Mounting (Kits Included)

WIRELESS FEATURES
- Wireless Client Capacity: 380+
- Wireless Standards: IEEE 802.11 a/b/g/n/ac/ax/be
- Frequency: 6 GHz, 5 GHz, and 2.4 GHz
- Signal Rate: 574 Mbps (2.4 GHz) + 4320 Mbps (5 GHz) + 5760 Mbps (6 GHz)
- Wireless Functions
• MLO
• 4K-QAM
• Seamless Roaming(802.11k/v/r)
• MU-MIMO
• EHT320
• Mesh
• BSS Coloring
• OFDMA
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS: 24 (8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS(WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication
- Wireless Security
• Captive Portal Authentication?
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- Transmission Power
< 25dBm (2.4GHz)
< 25dBm (5GHz)
< 23dBm (6GHz)

MANAGEMENT
- Omada App: Yes
- Centralized Management
• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
- Cloud Access: Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.
- Email Alerts: Yes
- LED ON/OFF Control: Yes
- Management MAC Access Control: Yes
- SNMP: v1, v2c, v3
- System Logging Local/Remote Syslog: Yes
- Web-based Management Yes

OTHERS
- Certification: CE, FCC, RoHS, IC
- Package Contents
• EAP772
• Installation Guide
• Ceiling/Wall Mounting Kit
*Note: Power Adapter is NOT included.
- Environment
• Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing;
