- Faster Connections: Wi-Fi 6 speeds up to 1.800Mbps - 1.201Mbps on 5GHz and 574Mbps on 2.4GHz
- Connect More Devices: OFDMA and MU-MIMO technology quadruple capacity to enable simultaneous transmission to more devices
- Boosted Seamless Coverage: Achieve seamless whole home coverage with a clearer and stronger whole home Wi-Fi signal generated by Wi-Fi 6
- Ultra-Low Latency: Greater reduction in latency enables more responsive gaming and video chatting
- One Unified Network: Multiple units form a whole-home network that auto-selects the best connection as you move around your home
- Total Security: WPA3 encryption and TP-Link HomeCareTM provide personalized features, including Parental Controls, Antivirus, and Quality of Service (QoS) to ensure a safer online experience
- Setup Made Easier Than Ever: The Deco app walks you through setup step-by-step

Specifications
WIRELESS
- Standards: Wi-Fi 6
* IEEE 802.11ax/ac/n/a 5 GHz
* IEEE 802.11ax/n/b/g 2.4 GHz
- WiFi Speeds: AX1800
* 5 GHz: 1201 Mbps (802.11ax)
* 2.4 GHz: 574 Mbps (802.11ax)
- WiFi Range: 4-6 Bedroom Houses
* TP-Link Mesh Technology: Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
* 2× Antennas (Internal): Multiple antennas form a signal-boosting array to cover more directions and large areas
* Beamforming: Concentrates wireless signal strength towards clients to expand WiFi range
- WiFi Capacity: High
* Dual-Band: Distribute devices to different bands for optimal performance
* MU-MIMO: Silmultaneously communicates with multiple MU-MIMO clients
* OFDMA: Silmultaneously communicates with multiple WiFi 6 clients
* 4 Streams: More than enough bandwidth for connected devices
- Working Modes: Router Mode, Access Point Mode

HARDWARE
- Processor: 1.0GHz Quad-Core CPU
- Ethernet Ports: 2× Gigabit Ports
- Supports WAN/LAN auto-sensing
- Buttons: Reset Button
- Power: 12V = 1.2A

SECURITY
- WiFi Encryption: WPA, WPA2, WPA3
- Network Security: SPI Firewall, Access Control
* HomeCare Antivirus: Malicious Site Checker, Port Intrusion Prevention, Infected Device Isolation, Notification and Log
- Guest Network:
* 1× 5 GHz Guest Network
* 1× 2.4 GHz Guest Network

SOFTWARE
- Protocols: IPv4, IPv6
- Service Kits: HomeCare
- Parental Controls: HomeCare Parental Controls
* Custom Profiles, Content Filtering, URL FIltering, Time Limit, Time Schedule (Bed Time), Log Insight, Usage Monitor, Monthly Reports
- WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
- Quality of Service: HomeCare QoS
* QoS by Device, QoS by Application
- Cloud Service: OTA Firmware Upgrade, TP-Link ID, DDNS
- NAT Forwarding: Port Forwarding, Port Triggering, DMZ, UPnP
- IPTV: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
- DHCP: Address Reservation, DHCP Client List, Server
- DDNS: TP-Link
- Management: Deco App

PHYSICAL
- Dimensions (W×D×H): 110×110×114 mm
- Package Contents:
3 Deco X20 Unit
1 RJ45 Ethernet Cable
3 Power Adapter
1 Quick Installation Guide

OTHERS
- System Requirements: Android 4.4 or later, iOS 9.0 or later
- Certifications: CE, FCC, IC, RoHS, RCM, JPA, JRF, VCCI
- Environment:
* Operating Temperature: 0C to 40C (32F to 104F)
* Storage Temperature: -40C to 70C (-40F to 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing

TEST DATA
- WiFi Transmission Power:
* CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)
* FCC: <30 dBm (2.4 GHz), <30 dBm (5 GHz)
