- High-Performance Wi-Fi for the Mainstream
- 802.11ac Wave2 Wi-Fi - 1300 Mbps on the 5 GHz band and 600 Mbps on the 2.4 GHz band
- 3×3 MIMO Technology - Transmitting and receiving data on three streams to pair flawlessly with your 3×3 clients
- Boosted Wi-Fi Coverage - Beamforming technology delivers a highly efficient wireless connection
- MU-MIMO - To help your devices achieve optimal performance by making communication more efficient
- Personalized Management - Advanced features like Parental Controls, Guest Network, and Access Control provide individualized tools for network management
- Intelligent Connection - Smart Connect directs clients to the less congested band and Airtime Fairness optimizes the time usage

Specifications
HARDWARE FEATURES
- Interface:
* 4× 10/100/1000Mbps LAN Ports
* 1× 10/100/1000Mbps WAN Port
- Button: Reset Button, WPS/Wi-Fi Button, Power On/off Button
- External Power Supply: 12V/1A
- Dimensions (W×D×H): 215×117×32 mm
- Antenna: 4× Fixed Omni Directional Antennas

WIRELESS FEATURES
- Wireless Standards:
* IEEE 802.11a/n/ac 5 GHz
* IEEE 802.11b/g/n 2.4 GHz
- Frequency: 2.4 GHz and 5 GHz
- Signal Rate: 1300 Mbps on 5 GHz + 600 Mbps on 2.4 GHz
Reception Sensitivity:
* 5 GHz:
11a 6Mbps:-98dBm, 11a 54Mbps:-78dBm
11ac VHT20_MCS0:-98dBm, 11ac VHT20_MCS8:-72dBm
11ac VHT40_MCS0:-92dBm, 11ac VHT40_MCS9:-68dBm
11ac VHT80_MCS0:-89dBm, 11ac VHT80_MCS9:-64dBm
* 2.4 GHz:
11g 6Mbps:-97dBm, 11a 54Mbps:-77dBm
11n VHT20_MCS0:-97dBm, 11n VHT20_MCS8:-72dBm
11n VHT40_MCS0:-92dBm, 11n VHT40_MCS9:-67dBm
- Transmit Power:
* CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.25 GHz)
* FCC:<30dBm(2.4 GHz & 5 GHz)
- Wireless Functions: Enable/Disable Wireless Radio, WMM
- Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
- Guest Network: 2.4 GHz Guest Network, 5 GHz Guest Network

SOFTWARE FEATURES
- Quality of Service: Device Prioritization
- WAN Type: Dynamic IP/Static IP/PPPoE(Dual Access)/PPTP(Dual Access)/L2TP(Dual Access)
- Management: Parental Controls, Local Management, Remote Management
- DHCP: Server, DHCP Client List, Address Reservation
- Port Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ
- Dynamic DNS: DynDns, NO-IP, TP-Link
- Access Control: Local Management Control, White List, Black List
- Firewall Security: SPI Firewall, IP and MAC Address Binding
- Protocols: Supports IPv4 and IPv6
- Advanced Features:
* MU-MIMO
* Beamforming
* Smart Connect
* Airtime Fairness
* Quality of Service

OTHERS
- Certification: CE, FCC, RoHS
- Package Contents: Wireless Router Archer C80, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide
- System Requirements:
* Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
* Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
* Java-enabled browser
* Cable or DSL Modem
* Subscription with an internet service provider (for internet access)
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
