- Deco uses a system of units to achieve seamless whole-home Wi-Fi coverage — eliminate weak signal areas once and for all!

- With advanced Deco Mesh Technology, units work together to form a unified network with a single network name. Devices automatically switch between Decos as you move through your home for the fastest possible speeds.

- A Deco M4 delivers Wi-Fi to an area of up to 180 square metres. And if that’s not enough, simply add more Decos to the network anytime to increase coverage.

- Deco M4 provides fast and stable connections with speeds of up to 1167 Mbps and works with the major internet service provider (ISP) and modem.

- Deco can handle traffic from even the busiest of networks, providing lag-free connections for up to 100 devices.

- Parental Controls limits online time and block inappropriate websites according to unique profiles created for each family member.

- Setup is easier than ever with the Deco app there to walk you through every step.

Specifications
POWER
- AC adapter input: 100-240V ~ 50/60Hz 0.4A
- AC adapter output: 12V = 1.2A

HARDWARE FEATURES
- Processor: Qualcomm CPU
- Interface: 2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit
- Button: 1 Reset button on the underside
- External Power Supply: 12 V/1.2 A
- Dimensions: ?3.6 in. x 7.5 in. (?90.7 mm x 190 mm)
- Antenna Type: 2 internal dual-band antennas

WIRELESS FEATURES
- Wireless Standards: IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz
- Frequency: 2.4 GHz and 5 GHz
- Signal Rate:
• 300 Mbps on 2.4 GHz
• 867 Mbps on 5 GHz
- Transmit Power
- FCC: <30 dBm
- CE:
• <20 dBm (2.4 GHz)
• <23 dBm (5 GHz)
- Wireless Security: WPA-PSK/WPA2-PSK
- Advanced Functions
• Router/ Access Point Mode
• Optional Ethernet Backhaul
• Guest network
• TP-Link Mesh Technology:
• MU-MIMO
• Auto Path Selection
• Self-Healing
• AP Steering
• Band Steering
• Beamforming

SOFTWARE FEATURES
- Quality of Service: WMM
- IPv6: Support
- WAN Type: Dynamic IP/Static IP/PPPoE/L2TP/PPTP
- Management: Local Management, Remote Management
- DHCP: Server, Client
- Port Forwarding: Support
- Access Control: Blacklist
- Firewall Security: SPI Firewall
- Protocols: Supports IPv4 and IPv6
- Advanced Features
• Parental Controls
• Quality of Service
- Advanced Functions
• Monthly Reports
• Auto FW Update
• Expand Wi-Fi by adding more Deco units
- Guest Network
• 2.4 GHz guest network x 1
• 5 GHz guest network x 1
- Beamforming: Support
- APP: Easy setup via Deco App

OTHERS
- Certification: CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS
- Package Contents
• 1 Deco units
• 1 RJ45 Ethernet Cable
• 1 power adapters
• 1 quick installation guide
- Smartphone/Tablet Requirements: iOS 9.0 or later, Android 4.4 or later
- Environment
• Operating Temperature: 0?~40? (32?~104?)
• Storage Temperature: -40?~70? (-40?~158?)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
