Features
- 10/100/1000Mbos Auto-Negotiation RJ45 port supporting Auto-MDI/MDIX
- Green Ethernet technology saves power
- IEEE 802.3X flow control provides reliable data transfer
- Steel housing, desktop or wall-mounting design
- Support 802.1p/DSCP QoS function
- Plug and play, no configuration needed

Specifications
HARDWARE FEATURES
- Standards and Protocols: IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p
- Interface: 8 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports
- Fan Quantity: Fanless
- External Power Supply: External Power Adapter
• V1, V3: 9VDC / 0.6A
• V2: 5VDC / 0.6A
- LED Indicator: System Power
- Link/Act indicators per port built into each RJ-45 port
- Dimensions ( W x D x H ): 6.2 x 3.9 x 1.0 in. (158 x 99.1x 25 mm)
- Max Power Consumption: 3.7W (220V/50Hz)
- Max Heat Dissipation: 12.617 Btu/hr

PERFORMANCE
- Packet Forwarding Rate: 11.9 Mpps
- MAC Address Table: 4K
- Packet Buffer Memory: 1.5 Mb
- Jumbo Frame: 16 KB

SOFTWARE FEATURES
- Advanced Features
• Green Technology
• 802.3X Flow Control
• 802.1P/DSCP QoS
- Transfer Method: Store and Forward

OTHERS
- Certification: CE, FCC, RoHS
- Package Contents
• 8-Port 10/100/1000Mbps Desktop Switch
• Power Adapter
• Installation Guide
- Environment
• Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~70°C (-40°F~158°F)
• Operating Humidity: 10% ~ 90% non-condensing
• Storage Humidity: 5%~90% non-condensing
