Features
- Auto negotiation of 10/100Mbps and auto MID/MID-X for TX port
- Provide switch configuration of Half-Duplex / Full-Duplex transfer mode for FX port
- Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely
- Extend fiber distance up to 20-60km
- Easy-to-view LED indicators provide status to monitor network activity easily
- External power supply

Specifications
- Standards and Protocols: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Basic Function:
* Half/Full-Duplex transfer mode for FX port
* Full Duplex Flow Control (IEEE 802.3x)
* Half Duplex Flow Control (Backpressure)
* Extends fiber distance up to 20km
* Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely
- Ports:
* 1× 100M SC port
* 1× 100M RJ45 port (Auto MDI/MDIX)
- Network Media:
* 10BASE-T - UTP category 3, 4, 5 cable (max. 100m); EIA/TIA-568 100 Ohm STP (max. 100m)
* 100BASE-T: UTP category 5, 5e cable (max. 100m); EIA/TIA-568 100 Ohm STP (max. 100m)
* 100BASE-FX: Single-mod Fiber
- LED Indicators: PWR, FDX/Col, Link/Act, SPD
- Safety & Emission: FCC, CE
- Dimensions (W×D×H): 94.5×73.0×27.0 mm
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
- Power Supply: External Power Adapter
