Performance
- Up to 7,250MB/s of sequential read speed, 45% faster speed than the previous model.
It says "73% Enhanced" on the dashboard. Power efficiency
- Power efficiency enhanced by 73% for more MB/s per watt, while maintaining performance and thermal control.
It says "Up to 4TB" inside two connected circles. Versatility
- Up to 4TB expanded capacity and rapid Intelligent. TurboWrite 2.0 with enlarged TurboWrite region.
Spectacular speed everyday
- Blast through tasks faster. 990 EVO Plus with the latest NAND offers boosted sequential read/write speeds up to 7,250/6,300MB/s1. Huge files, instant transfer.
Cool power through your day
- Optimised efficiency, extended performance. The nickel-coated controller increases MB/s per Watt by 73%, achieving the same power level and thermal control with less power consumption. Stay focused on work or play with no overheating or battery life worries.
Extra space. Extra speed.
- Harness the full power of your drive with enhanced Intelligent TurboWrite 2.0. Process massive data faster and breeze through heavy graphics with an enlarged TurboWrite region, now available in 4TB capacity.
Samsung Magician software
- Make your SSD work like magic. Samsung Magician softwares optimisation tools ensure the best SSD performance. Its a safe and easy way to migrate all your data for a Samsung SSD upgrade. Protect valuable data, monitor drive health, and get the latest firmware updates.
Bringing innovations to life
- For decades, Samsung’s NAND flash memory has powered ground-breaking technologies that have changed our daily lives. This NAND flash technology also powers our SSDs, making room for the next big push of innovation.
Specifikacije
General Feature:
- Application: Client PCs
- Rated Capacity: 2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
- Form Factor: M.2 (2280)
- Interface: PCIe 4.0 x4 / 5.0 x2 NVMe 2.0
- Dimension (Pack: WxHxD): Max 80.15 x Max 22.15 x Max 2.38 mm
- Weight: Max 9.0g Weight
- Storage Memory: Samsung V-NAND TLC
- Controller: Samsung in-house Controller
- Cache Memory: HMB(Host Memory Buffer)
Special Feature:
- TRIM Support: Supported
- S.M.A.R.T Support: Supported
- GC (Garbage Collection): Auto Garbage Collection Algorithm
- Encryption Support: AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
- WWN Support: Not supported
- Device Sleep Mode Support: Yes
Performance
- Sequential Read: Up to 7,250 MB/s *
- Sequential Write: Up to 6,300 MB/s *
- Random Read (4KB, QD32): Up to 1,000,000 IOPS * Performance may vary based on system hardware & configuration
- Random Write (4KB, QD32): Up to 1,350,000 IOPS * Performance may vary based on system hardware & configuration
Environment
- Average Power Consumption (system level): Average: Read 4.6 W / Write 4.2 W* Actual power consumption may vary depending on system hardware & configuration
- Power consumption (Idle): Typical 60 mW * Actual power consumption may vary depending on system hardware & configuration
- Power Consumption (Device Sleep): Typical 5 mW * Actual power consumption may vary depending on system hardware & configuration
- Allowable Voltage: 3.3 V ± 5 % Allowable voltage
- Reliability (MTBF): 1.5 Million Hours Reliability (MTBF)
- Operating Temperature: 0 - 70 C Operating Temperature
- Shock: 1,500 G & 0.5 ms (Half sine)
Accessories
- Installation Kit: Not Available
Software
- Management SW: Magician Software for SSD management
