Description
- The system is composed of a 19" patch panel frame and the UTP Cat.6 RJ-45 keystone jacks
- Assembling of cables and keystones takes place over LSA-plus or toolless
- Colour code on the keystone jacks, based on the standard EIA/TIA 568 A and 568 B
- For a structured unshielded Cat.6 cabling system we recommend to use the following components:
* ROLINE Cat.6 UTP Cable, Solid Wire, AWG23: 21.15.0990 (100 m), 21.15.0991 (300 m)
* Flush Mount Wall Jack for Keystones, unloaded: 25.16.8579
* ROLINE Cat.6 Keystone, RJ-45, unshielded: 26.11.0352 (black), 26.11.0353 (white)
* 19" Keystone Patch Panel, 24 Ports, unshielded: 26.11.0356 (light grey), 26.11.0357 (black)
* ROLINE Cat.6 UTP Patch Cord, grey, 5 m: 21.15.0935

Technical Data
- Colour: Black
- Shield type: Not screened
- Transfer quality: Cat6 / Class E
- Quantity of ports: 24
- Assembly cable connection: Krone LSAplus
- Assignment: EIA/TIA 568A & 568B
- Modular assembly: Yes
- Connection direction: Straight
