- Its time to supercharge your home network with the Generation 6 wireless network and our latest addition to the beloved hAP series
- hAP ax has everything you might need in a primary home access point - and more!
- Forget endless reviews and comparisons - this is the perfect device for 99% of homes
- Wireless signal is now stronger than ever
- Here are the two main ingredients of hAP axs success: a state-of-the-art dual-band, dual-chain 4-4.5 dBi radio, and the 802.11ax standard with Wave2 support
- Lets compare it to the previous generation: depending on your overall setup, that means up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum!
- Some might ask - why do we even need higher wireless speeds ?
- Well, countless use cases have been previously impossible or difficult to pull off
- For example, working with large media files over the wireless network - without the need to download and upload everything
- Do you really have the time to wait ?
- Grab a hAP ax and save more time for the essential things in life !
- The modern quad-core CPU running at 864 MHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using more threads or experimenting with the most advanced RouterOS features
- And with the addition of WPA3 advanced encryption support, youre safer than ever before
- Like the previous models, hAP ax can be mounted vertically, horizontally, or even on the wall - without sacrificing the strong signal
- With so many products and features on the market, even an experienced user can become confused
- So its time for a simple truth for a simple choice: you cant go wrong with a hAP ax in most homes

Specifications
- Architecture: ARM 64bit
- CPU: IPQ-6010
- CPU core count: 4
- CPU nominal frequency: 864 MHz
- RouterOS license: 4
- Operating System: RouterOS (v7 only)
- Size of RAM: 1 GB
- Storage size: 128 MB
- Storage type: NAND
- MTBF: Approximately 100000 hours at 25C
-Tested ambient temperature: -40C to 50C

WIRELESS
- Wireless 5 GHz Max data rate: 1200 Mbit/s
- Wireless 5 GHz number of chains: 2
- Wireless 5 GHz standards: 802.11a/n/ac/ax
- Antenna gain dBi for 5 GHz: 4
- Wireless 5 GHz chip model: QCN-5052
- Wireless 5 GHz generation: Wi-Fi 6
- Wireless 2.4 GHz Max data rate: 574 Mbit/s
- Wireless 2.4 GHz number of chains: 2
- Wireless 2.4 GHz standards: 802.11b/g/n/ax
- Antenna gain dBi for 2.4 GHz: 4.5
- Wireless 2.4 GHz chip model: QCN-5022
- Wireless 2.4 GHz generation: Wi-Fi 6
- WiFi speed: AX1800

ETHERNET
- 10/100/1000 Ethernet ports: 5
- Number of 1G Ethernet ports with PoE-out: 1

POWERING
- Number of DC inputs: 2 (PoE-IN, DC jack)
- DC jack input Voltage: 12-28 V
- Max power consumption: 27 W
- Max power consumption without attachments: 12 W
- Cooling type: Passive
- PoE in: Passive PoE
- PoE in input Voltage: 18-28 V

PoE - OUT
- PoE-out ports: Ether 1
- PoE out: Passive PoE
- Max out per port output (input 18-30 V): 600 mA
- Max total out: 0.6 A
- Total output current: 0.6
- Total output power: 16.8W

CERTIFICATION & APPROVALS
- Certification: CE, FCC, IC, EAC, ROHS
- IP: 20

OTHER
- Mode button: Yes

INCLUDED PARTS
- 24V 1.2A power adapter
- hAP case base
- K-47 wall mount set
