Specifications
PERFORMANCE
- Processor: AMD Ryzen 7 7735HS (8C / 16T, 3.2 / 4.75GHz, 4MB L2 / 16MB L3)
- Graphics: Integrated AMD Radeon 680M Graphics
- Chipset: AMD SoC Platform
- Memory: 2x 16GB SO-DIMM DDR5-4800
- Memory Slots: Two DDR5 SO-DIMM slots, dual-channel capable
- Max Memory: Up to 64GB DDR5-4800
- Storage: 1TB SSD M.2 2242 PCIe 4.0x4 NVMe
- Storage Support: Up to two drives, 2x M.2 SSD
• M.2 2280 SSD up to 2TB each
- Storage Slot: Two M.2 2280 PCIe 4.0 x4 slots
- Card Reader: SD Card Reader
- Optical: None
- Audio Chip: High Definition (HD) Audio, Realtek ALC3287 codec
- Speakers: Stereo speakers, 2W x2, Dolby Audio
- Camera: FHD 1080p + IR Hybrid with Privacy Shutter
- Microphone: 2x, Array
- Battery: Integrated 45Wh
- Power Adapter: 65W USB-C (3-pin)
- Special Features: Modern Standby

DESIGN
- Display: 16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC
- Touchscreen: None
- Keyboard: Backlit, Croatian
- Touchpad: Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
- Case Color: Arctic Grey
- Surface Treatment: Anodizing Sandblasting
- Case Material: Aluminium (Top), PC-ABS (Bottom)
- Pen: Pen Not Supported
- Dimensions (WxDxH): 356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches)
- Weight: Starting at 1.7 kg (3.75 lbs)

SOFTWARE
- Operating System: Win 11 Pro
- Bundled Software: None

CONNECTIVITY
- Ethernet: 100/1000M (RJ-45)
- WLAN + Bluetooth: Wi-Fi 6E, 802.11ax 2x2 + BT5.3
- WWAN: Non-WWAN
- Standard Ports
• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
• 1x USB-C (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.0 and DisplayPort 1.4
• 1x USB-C (USB4 40Gbps), with USB PD 3.0 and DisplayPort 1.4
• 1x HDMI 2.1, up to 4K/60Hz
• 1x Headphone / microphone combo jack (3.5mm)
• 1x Ethernet (RJ-45)
• 1x SD card reader
- Docking: Various docking solutions supported via USB-C.
- For more compatible docking solutions, please visit Docking for ThinkBook 16 G7 ARP

SECURITY & PRIVACY
- Security Chip: Firmware TPM 2.0 Enabled
- Fingerprint Reader: Touch Style, Match-on-Chip, Integrated in Power Button
- Physical Locks: Kensington Nano Security Slot, 2.5 x 6 mm
- Other Security:
• IR camera for Windows Hello (facial recognition)
• Camera privacy shutter

SERVICE
- Warranty: 3 years

ACCESSORIES
- Bundled Accessories: None

CERTIFICATIONS
- Green Certifications
• ENERGY STAR 8.0
• ErP Lot 6/26
• RoHS compliant
• TCO Certified 9.0
- Other Certifications
• TÜV Rheinland Low Blue Light (Software Solution)
• Mil-Spec Test: MIL-STD-810H military test passed
